vaadin-ordered-layout

A set of two Web Components providing a simple way to horizontally or vertically align your HTML elements. Part of the Vaadin components.

Author

Rating

Popularity

<100

npm version Bower version Published on webcomponents.org Build Status Coverage Status Gitter

Published on Vaadin  Directory Stars on vaadin.com/directory

<vaadin-ordered-layout>

Live Demo ↗ | API documentation ↗

<vaadin-ordered-layout> consist of two Web Components providing a simple way to horizontally or vertically align your HTML elements, part of the Vaadin components.

<vaadin-horizontal-layout>
  <div>Horizontally</div>
  <div>Aligned</div>
</vaadin-horizontal-layout>
<vaadin-vertical-layout>
  <div>Vertically</div>
  <div>Aligned</div>
</vaadin-vertical-layout>

Screenshot of vaadin-ordered-layout

Installation

The Vaadin components are distributed as Bower and npm packages. Please note that the version range is the same, as the API has not changed. You should not mix Bower and npm versions in the same application, though.

Unlike the official Polymer Elements, the converted Polymer 3 compatible Vaadin components are only published on npm, not pushed to GitHub repositories.

Polymer 2 and HTML Imports Compatible Version

Install vaadin-ordered-layout:

bower i vaadin/vaadin-ordered-layout --save

Once installed, import it in your application:

<link rel="import" href="bower_components/vaadin-ordered-layout/vaadin-vertical-layout.html">

Polymer 3 and ES Modules Compatible Version

Install vaadin-ordered-layout:

npm i @vaadin/vaadin-ordered-layout --save

Once installed, import it in your application:

import '@vaadin/vaadin-ordered-layout/vaadin-vertical-layout.js';

Getting started

Vaadin components use the Lumo theme by default.

To use the Material theme, import the correspondent file from the theme/material folder.

Entry points

  • The components with the Lumo theme:

    theme/lumo/vaadin-horizontal-layout.html
    theme/lumo/vaadin-vertical-layout.html

  • The components with the Material theme:

    theme/material/vaadin-horizontal-layout.html
    theme/material/vaadin-vertical-layout.html

  • Alias for theme/lumo/vaadin-horizontal-layout.html
    theme/lumo/vaadin-vertical-layout.html:

    vaadin-horizontal-layout.html
    vaadin-vertical-layout.html

Running demos and tests in browser

  1. Fork the vaadin-ordered-layout repository and clone it locally.

  2. Make sure you have npm installed.

  3. When in the vaadin-ordered-layout directory, run npm install and then bower install to install dependencies.

  4. Run polymer serve --open, browser will automatically open the component API documentation.

  5. You can also open demo or in-browser tests by adding demo or test to the URL, for example:

Running tests from the command line

  1. When in the vaadin-ordered-layout directory, run polymer test

Following the coding style

We are using ESLint for linting JavaScript code. You can check if your code is following our standards by running gulp lint, which will automatically lint all .js files as well as JavaScript snippets inside .html files.

Contributing

To contribute to the component, please read the guideline first.

License

Apache License 2.0

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Dependencies

  • @polymer/polymer#^3.0.0
  • @vaadin/vaadin-themable-mixin#^1.2.1
  • @vaadin/vaadin-lumo-styles#^1.1.0
  • @vaadin/vaadin-material-styles#^1.1.0
  • @vaadin/vaadin-element-mixin#^2.0.0
Released
2018-08-20
Maturity
IMPORTED
License
Apache License 2.0

Compatibility

Framework
Polymer 2.0+
Polymer 3.0+
Browser
Browser Independent
