Vaadin TreeGrid

Component that adds tree-like functionality to Grid for displaying hierarchical data

View larger

Close

TreeGrid is a UI component add-on for Vaadin 7. It adds the ability to display and edit hierarchical data source in the Grid component (similar to TreeTable's extension to Table).

Features:

• Basic functionality for displaying hierarchical data in Grid
• CSS configurable hierarchy indicators
• Expand/collapse functionality on mouse click
• Programmatically settable hierarchy column
• Keyboard navigation (Alt/Option + Arrow keys)
• Support for custom renderer on hierarchy column
• Support for custom depth calculation logic
• Support for custom collapse logic

Notes:

• This add-on relies on changes in Vaadin Framework 7.7.6
• This add-on is compiled with Java 7

Sample code

final TreeGrid grid = new TreeGrid();

// Container implementing Hierarchical and Indexed interfaces
DemoContainer container = new DemoContainer();
grid.setContainerDataSource(container);

// Set the column that shows the hierarchy information
grid.setHierarchyColumn(DemoContainer.PROPERTY_LAST_NAME);

grid.setColumnReorderingAllowed(true);
