OpenLayers 2 Add-on

OpenLayers 2 add-on for Vaadin 7

Author

Rating

Popularity

<100

This add-on is a port of the excellent OpenLayers Wrapper add-on for Vaadin 6. It implements all of the same features as the Vaadin 6 version.

This add-on contains server side wrapper component for an OpenLayers 2 Map. It also provides API's for different types of layers.

The integration is built on its own GWT wrappers around OpenLayers javascript API. The GWT part is designed so that the add-on can also be used in plain GWT applications without Vaadin.

Some of the most essential features listed below:

  • Multiple base layers (E.g. WMS, TMS, Google maps, VirtualEarth (aka Bing), OpenStreetMap)
  • VectorLayer (Points, Areas, Lines, drawing, editing and styling either explicitly or via StyleMaps)
  • Popups
  • MarkerLayer (Users can start using VectorLayer instead. Also with plain OpenLayers)

The client side implementation is based on GWT's JavaScript overlays. Extending the API to any of OpenLayers features should be rather straightforward. Contributions, feature requests and bug reports are welcome via the Github project page.

Sample code

import com.vaadin.annotations.JavaScript;
import com.vaadin.annotations.Theme;
import com.vaadin.annotations.Title;
import com.vaadin.annotations.VaadinServletConfiguration;
import com.vaadin.server.VaadinRequest;
import com.vaadin.server.VaadinServlet;
import com.vaadin.ui.UI;

import javax.servlet.annotation.WebServlet;

import org.vaadin.vol.OpenLayersMap;
import org.vaadin.vol.OpenStreetMapLayer;

@Theme("demo")


@Title("OpenLayers 2 Add-on Demo")
@JavaScript({"http://openlayers.org/api/2.13/OpenLayers.js", "http://www.openstreetmap.org/openlayers/OpenStreetMap.js"})
@SuppressWarnings("serial")
public class DemoUI extends UI
{

    @WebServlet(value = "/*", asyncSupported = true)
    @VaadinServletConfiguration(productionMode = false, ui = DemoUI.class, widgetset = "org.vaadin.vol.demo.DemoWidgetSet")
    public static class Servlet extends VaadinServlet {
    }

    @Override
    protected void init(VaadinRequest request) {

        // Initialize our new UI component
        final OpenLayersMap map = new OpenLayersMap();
        map.setApiProjection("EPSG:4326");
        map.setSizeFull();

        // base layers
        OpenStreetMapLayer osmLayer = new OpenStreetMapLayer();
        //osmLayer.setUrl("http://b.tile.openstreetmap.org/${z}/${x}/${y}.png");
        osmLayer.setDisplayName("OSM");
        map.addLayer(osmLayer);
        map.setBaseLayer(osmLayer);

        map.setCenter(146.9417, -42.0429);
        map.setZoom(7);

        setContent(map);
    }

}

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Limit scope of context click event for markers to the markers themselves

Released
2016-02-04
Maturity
BETA
License
Apache License 2.0

Compatibility

Framework
Vaadin 7.6+
Browser
Firefox
Safari
Google Chrome
iOS Browser
Android Browser
Internet Explorer
Internet Explorer
