Provides feedback about device and orientation, using material design breakpoints.

[ This description is mirrored from README.md at github.com/IswPolymerElements/isw-responsive on 2019-05-10 ]

<isw-responsive>

isw-responsive calculates device and orientation according to material design breakpoints and pushes the result to all elementes using isw-responsive-behavior using iron-meta and iron-signals like events.

If there will be an iron-signals 2.0, the element will be updated to use it instead of custom document events.

https://material.io/guidelines/layout/responsive-ui.html#responsive-ui-breakpoints

isw-responsive

Calculates device and orientation from the current screen size.

Use it only once in your app, it will notify all isw-responsive-behavior elements about changes.

isw-responsive

Provides reflectToAttribute properties for css selectors, and events for imperative use.

iron-meta

isw-responsive writes the viewport information to iron-meta, so they are global available via these keys:

  • isw-responsive-device
  • isw-responsive-orientation

iron-signals

Future plans: If iron-signals will get an 2.0 update, the viewport-changed event should be exposed to iron-signals., e.g.:

  • isw-responsive-viewport-changed

Example: Useage with Starter Kit.

my-app.html

[...]

<!-- ISW Responsive imports -->
<link rel="import" href="../bower_components/isw-responsive/isw-responsive.html">
<link rel="import" href="../bower_components/isw-responsive/isw-responsive-behavior.html">

[...]

<dom-module id="my-app">
  <template>
    [...]

    <!-- isw-responsive definition that does the calculating and notifying. -->
    <isw-responsive></isw-responsive>

    [...]

    <!-- Deactivate app drawers responsive behavior for imperative example. -->
    <app-drawer-layout fullbleed responsive-width="0" force-narrow="[[_forceNarrow]]">

      [...]

    </app-drawer-layout>
  </template>

  <script>
    // Use Polymer.mixinBehaviors to assign the behavior to get device and orientation properties that reflect to attribute.
    class MyApp extends Polymer.mixinBehaviors([ iswResponsiveBehavior ], Polymer.Element ) {
      static get is() { return 'my-app'; }

      [...]

      constructor() {
        super();
        this.addEventListener( 'viewport-changed', e => this._viewportChanged( e ) );
      }

      [...]

      _viewportChanged() {
        // Manually set the drawers force narrow property depending on device and orientation (Imperative use example).
        switch( this.device ) {
          case 'desktop':
            this.set( '_forceNarrow', false );
            break;
          case 'tablet':
            this.set( '_forceNarrow', this.orientation == 'portrait' );
            break;
          default:
            this.set( '_forceNarrow', true );
        }
      }
    }
    window.customElements.define(MyApp.is, MyApp);
  </script>
</dom-module>

my-view1.html

[...]
<!-- ISW Responsive imports -->
<link rel="import" href="../bower_components/isw-responsive/isw-responsive-behavior.html">
[...]

<dom-module id="my-view1">
  <template>
    <style include="shared-styles">
      :host {
        display: block;
        padding: 10px;
      }

      // Use attribute selectors to assign css properties for certain devices or / and orientations.
      :host([device="desktop"]) .card {
        ...
      }
      :host([device="mobile"][orientation="landscape"]) .card {
        ...
      }
    </style>

    <div class="card">
      [...]
    </div>
  </template>

  <script>
    // Use Polymer.mixinBehaviors to assign the behavior to get device and orientation properties that reflect to attribute.
    class MyView1 extends Polymer.mixinBehaviors([ iswResponsiveBehavior ], Polymer.Element ) {
      static get is() { return 'my-view1'; }
    }
    window.customElements.define(MyView1.is, MyView1);
  </script>
</dom-module>

Install

Link to this version
ImportedReleased 28 November 2018Other
Framework Support
Polymer 2.0+
Browser Compatibility
Install with
Release notes - Version 2.0.0

Dependencies

Polymer/polymer#^2.0.0

  • PolymerElements/iron-meta#^2.0.2
