DiagnosticServlet
Custom servlet which enables setting component's communication id's with setId()-method
Experimental utilities (DiagnosticServlet and DiagnosticInterceptor) for tests and diagnostics.
DiagnosticServlet
Experimental and simple custom servlet which enables setting component's communication id's. This will help one to write scalability tests for Vaadin with e.g JMeter or Gatling.
For VAADIN 8.1 use ConnectorIdGenerator add-on instead
See the following wiki articles for more information about the scalability testing: http://bit.do/vaadin-gatling http://bit.do/vaadin-jmeter
Caution! Use unique ids for components!
DiagnosticInterceptor
Server-side interceptor for recording Push WebSocket communication. You can use recorded requests e.g. for scalability testing a Vaadin application with JMeter. See also (https://github.com/johannest/JMeter-WebSocketSampler) for a customized WebSocketSampler plugin for JMeter.
Sample code
public class MyVaadinUI extends UI { @WebServlet(value = "/*", asyncSupported = true, initParams = { // disables xsrf forgering protection, not good for production, but makes // load testing easier @WebInitParam(name = "disable-xsrf-protection", value = "true"), // disables syncid verifation in vaadin client-server communiction // not good for production, but makes load testing easier @WebInitParam(name = "syncId", value = "false"), }) @VaadinServletConfiguration(productionMode = false, ui = MyVaadinUI.class) public static class Servlet extends DiagnosticAndTestServlet { } @Override protected void init(VaadinRequest request) { final VerticalLayout layout = new VerticalLayout(); layout.setMargin(true); setContent(layout); final TextField tf = new TextField("test"); tf.setId("test-textfield"); tf.addValueChangeListener(new ValueChangeListener() { @Override public void valueChange(ValueChangeEvent e) { System.out.println("Text input: "+e.getProperty().getValue()); } }); Button button = new Button("Click Me"); button.setId("click-me-button"); button.addClickListener(new ClickListener() { @Override public void buttonClick(ClickEvent e) { System.out.println("Button clicked"); layout.addComponent(new Label("Thank you for clicking: "+tf.getValue())); } }); layout.addComponents(tf,button); } }
@Override protected void init(VaadinRequest request) { // 1. clear all previously recorded requests DiagnosticInterceptor.clearRecordedRequests(); // some ui code // ... Button button = new Button("Show recorded request frames with pauses"); button.setId("show-requests-button"); button.addClickListener(e->{ // 2. fetch requests recorded this far String requestsLines = DiagnosticInterceptor.getRecordedRequesWithPauses(); // 3. then show them, log them or export into file Label label = new Label(requestsLines, ContentMode.PREFORMATTED); label.addStyleName(ValoTheme.LABEL_TINY); layout.addComponent(label); }); // ... }
Links
Compatibility
Was this helpful? Need more help?
Leave a comment or a question below. You can also join
the chat on Discord or
ask questions on StackOverflow.
Version
Vaadin 8.0 version
- Released
- 2017-06-29
- Maturity
- EXPERIMENTAL
- License
- Apache License 2.0
Compatibility
- Framework
- Vaadin 8.0
- Vaadin 7.3+ in 0.1.3
- Browser
- Browser Independent
