VostokSystem UIComponents collection

A collection of UIcomponents and helper classes, Toolbar, PushButton, SpinButton, ActionWindow and more

Author

Rating

Popularity

<100

This library regroups several components and helpers classes, main ones are :

Toolbar is a widget for rendering an horizontal toolbar, filled with buttons, selectors, etc.
It aims to be simple and versatile. It also provide a set of scss variables.

PushButton is a on/off state button. It accepts 3 different modes, Single, Many to Many, One of many.

SpinButton is a multi purpose component, designed to display and browse over data with next/previous buttons. it uses a data model, therefore values aren't necessarily fixed neither linear and can be done at request.There's a set of default models but you can easily create your. value can also be edited by user.

Dialog window - which extend Dialog - is made of two parts, the inner, where you add your content, and the button bar. It uses a central listener for managing all actions at once (including close/cancel), no need for a listen on each button. To do so, It expects an unique "id" for each button (action). ActionWindow provides many helpers to create most common "modal" windows.

KeyPressAction allow you to register a specific listener for a component when using the same shortcut accross several others component. It acts as a proxy between components and the default vaadin Shortcut listener.

also,, i18nbutton, i18n integration, WindowManagement, SimpleColourWindow, HintField...

Check the sampler at http:/:vaadin.vostoksystem.eu for a full description and more samples code.

Licence : Creative commons, no restriction, free for any open source or commercial usages.

Thanks.

Sample code

new Toolbar() {
	Button.ClickListener listener = new Button.ClickListener() {
		@Override
		public void buttonClick(Button.ClickEvent event) {
			NotificationExtension.showOk("Button clicked", "button : " + event.getButton().getCaption());
		}
	};
	{
		addButton("Home", "Go to home", "home").addClickListener(this.listener);
		addButton("New", "new document", "new").addClickListener(this.listener);
		addButton("Open", "open", "open").addClickListener(this.listener);
		addButton("Close", "close current", "close").addClickListener(this.listener);
		addSeparator();
		addButton("Copy", "Copy", "copy").addClickListener(this.listener);
		addButton("Cut", "Cut", "cut").addClickListener(this.listener);
		addButton("Paste", "Paste", "paste").addClickListener(this.listener);
		addButton("About", "About this", "about", BANK.RIGHT).addClickListener(this.listener);
		addButton("Help", "Inline help", "help", BANK.RIGHT).addClickListener(this.listener);

	}
};
addComponent(new Label("Simple integer, no limit"));
addComponent(new SpinButton(new NumberModel(10)));

/****************************/
addComponent(new Label("Currencies : 0 to 99.99€, 10€ increase"));
addComponent(new SpinButton(new NumberModel(9.99, 10.0, 0, 99.99, false, NumberModel.FORMAT_CURRENCY_EURO)));

/****************************/
addComponent(new Label("Geometry : 15° step"));
addComponent(new SpinButton(new NumberModel(0, 15.0, -180, 180, true, "%.02f °")));
/* With property listener */
// add a data source and set initial button
final ObjectProperty<Integer> value = new ObjectProperty<Integer>(-1);
final PushButton buttons = new PushButton(null,
	new I18nButton("grid-large"), new I18nButton("grid-normal"), new I18nButton("grid-condensed"), new I18nButton("grid-list")) {
		{
			setPropertyDataSource(value);
			setMode(Mode.ONEMANY);

			addValueChangeListener(new ValueChangeListener() {

				@Override
				public void valueChange(Property.ValueChangeEvent event) {
					NotificationExtension.showOk("property changed : " + event.getProperty().getValue());
				}
			});
		}
	};

/* forcing state */
new Button("Click to switch button #4", new Button.ClickListener() {

	@Override
	public void buttonClick(Button.ClickEvent event) {
		buttons.setValue(3);
	}
});
/**
A "movie" list window with an inner preview window to
**/

/*
create the window
*/
dlg = new DialogWindow("Movie list", new DialogWindow.Item[]{
	new Item("preview",  100),
	new Item("save",  DialogWindow.OK),
	new Item("cancel",  DialogWindow.CANCEL)
}) {
	{
		setId("MovieListDemoDlg");
		center();
		setDialogClickListener(new DialogClickListener() {

			@Override
			public boolean buttonClick(Event event, int action) {
				switch (action) {
					case OK:
						NotificationExtension.showOk("Should submit change to db.<br/>Obviously here does nothing");
						break;

					case 100:
						// let's  create a simple preview window.
						//Note in this case (htm content), use of dialogWindow.createMessage should be used instead
						StringBuilder sb = new StringBuilder("<ul>");
						for (Iterator i = contexteContainer.getItemIds().iterator(); i.hasNext();) {
							MovieBean m = contexteContainer.getItem(i.next()).getBean();
							sb.append("<li>").append(m.getYear()).append(", ").append(m.getTitle()).append("</li>");
						}
						sb.append("</ul>");

						new DialogWindow("Preview", new Label(sb.toString()) {
							{
								setContentMode(ContentMode.HTML);
							}
						}, new Item[]{
							new Item("close",  DialogWindow.CLOSE),}) {
							{
								setModal(true);
							}
						}.show();

						return false;

					case CLOSE:
						NotificationExtension.showOk("Window closed by icon");
						break;

					default:
					// fake close / cancel, just reload data
				}

				return true;
			}
		});
	}
};

Table table = new Table("Movie list") {
	{
		setSizeFull();
		setImmediate(true);

		setContainerDataSource(contexteContainer);

		setSortContainerPropertyId("year");
		setSortAscending(false);

		setVisibleColumns("title", "year");
		setColumnHeaders(new String[]{"Title", "Year"});
	}
};

dlg.getInnerContent().addComponent(table);
dlg.getInnerContent().setSizeFull();

/*
use it
*/
new Button("Open Dialog", new Button.ClickListener() {
	@Override
	public void buttonClick(Button.ClickEvent event) {

		if (WindowManagement.show("MovieListDemoDlg")) {
			return;
		}
		CreateDialogView.this.dlg.show();
	}
});

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Library switches to scss and valo Minor bug fixes, Compatibility with vaddin 1.5 and up updated license to Apache 2.0

Released
2016-05-30
Maturity
STABLE
License
Apache License 2.0

Compatibility

Framework
Vaadin 7.5
Vaadin 7.6
Vaadin 7.2 in 1.1.2
Vaadin 7.1 in 1.1.2
Browser
N/A
