vaadlets - addon

Vaadlets

Vaadlets is a template engine for vaadin.

Imagine you can use a library like Facelets (Java Server Faces) in your Vaadin application.

The ui declaration in Vaadlets is xml/xsd based, so you have auto completion etc.

Sample code

<?xml version="1.0" encoding="UTF-8"?>
<vaadlets xmlns="http://www.mymita.com/vaadlets/1.0.0"
      xmlns:core="http://www.mymita.com/vaadlets/core/1.0.0"
      xmlns:layout="http://www.mymita.com/vaadlets/layout/1.0.0"
      xmlns:ui="http://www.mymita.com/vaadlets/ui/1.0.0"
      xmlns:input="http://www.mymita.com/vaadlets/input/1.0.0"
      xmlns:addon="http://www.mymita.com/vaadlets/addon/1.0.0"
      xmlns:xsd="http://www.w3.org/2001/XMLSchema-instance"
      xsd:schemaLocation="http://www.mymita.com/vaadlets/1.0.0 http://www.mymita.com/xsd/vaadlets-1.0.0.xsd
                          http://www.mymita.com/vaadlets/core/1.0.0 http://www.mymita.com/xsd/vaadlets-core-1.0.0.xsd
                          http://www.mymita.com/vaadlets/layout/1.0.0 http://www.mymita.com/xsd/vaadlets-layout-1.0.0.xsd
                          http://www.mymita.com/vaadlets/ui/1.0.0 http://www.mymita.com/xsd/vaadlets-ui-1.0.0.xsd
                          http://www.mymita.com/vaadlets/input/1.0.0 http://www.mymita.com/xsd/vaadlets-input-1.0.0.xsd
                          http://www.mymita.com/vaadlets/addon/1.0.0 http://www.mymita.com/xsd/vaadlets-addon-1.0.0.xsd">
  <ui:window caption="Vaadlets Editor">
    <ui:window caption="Welcome" width="300px" height="200px" center="true" resizeable="false" modal="true">
      <ui:label caption="Welcome to the Vaadlets DEMO Application"/>
    </ui:window>
    <ui:horizontalSplitPanel>
      <layout:verticalLayout size-full="true" margin="true" spacing="true">
        <ui:panel size-full="true" expand-ratio="1.0">
          <layout:verticalLayout size-full="true" >
            <addon:codeMirror id="editor" size-full="true" expand-ratio="1.0" code-style="XML" style-name="foobar"/>
          </layout:verticalLayout>
        </ui:panel>
        <layout:horizontalLayout>
          <input:button id="test" caption="Test Vaadlet"/>
          <input:button id="reset" caption="Reset Vaadlet"/>
        </layout:horizontalLayout>
      </layout:verticalLayout>
      <ui:panel id="content" size-full="true">
        <layout:verticalLayout margin="true" size-full="true"/>
      </ui:panel>
    </ui:horizontalSplitPanel>
  </ui:window>
</vaadlets>

package com.mymita.vaadlets.demo;

import java.io.ByteArrayInputStream;
import java.io.IOException;
import java.io.InputStreamReader;
import java.io.PrintWriter;
import java.io.StringWriter;

import org.apache.commons.logging.Log;
import org.apache.commons.logging.LogFactory;
import org.springframework.core.io.ClassPathResource;

import com.google.common.io.CharStreams;
import com.mymita.vaadlets.VaadletsBuilder;
import com.vaadin.Application;
import com.vaadin.ui.Button;
import com.vaadin.ui.Button.ClickEvent;
import com.vaadin.ui.Button.ClickListener;
import com.vaadin.ui.Label;
import com.vaadin.ui.Panel;
import com.vaadin.ui.TextField;
import com.vaadin.ui.VerticalLayout;
import com.vaadin.ui.Window;

public class AddonDemoApplication extends Application {

  private static final Log LOG = LogFactory.getLog(AddonDemoApplication.class);

  private static final long serialVersionUID = 4745768698981212574L;

  private static VerticalLayout createStackTraceLabel(final Exception e) {
    final VerticalLayout vl = new VerticalLayout();
    vl.setMargin(true);
    vl.addComponent(new Label("<h1>Error</h1>", Label.CONTENT_XHTML));
    final StringWriter buf = new StringWriter();
    e.printStackTrace(new PrintWriter(buf));
    vl.addComponent(new Label(buf.toString(), Label.CONTENT_PREFORMATTED));
    return vl;
  }

  private static void fillEditorWithDefaultXML(final VaadletsBuilder vaadlets) {
    vaadlets.<Panel>getComponent("content").getContent().removeAllComponents();
    final TextField editor = vaadlets.getComponent("editor");
    try {
      editor.setValue(CharStreams.toString(new InputStreamReader(new ClassPathResource("startingPoint.xml",
          AddonDemoApplication.class).getInputStream(), "UTF-8")));
    } catch (final IOException e) {
    }
  }

  @Override
  public void init() {
    final VaadletsBuilder vaadlets = new VaadletsBuilder();
    try {
      vaadlets.build(new ClassPathResource("demo.xml", AddonDemoApplication.class).getInputStream());
    } catch (final IOException e) {
      LOG.error("error", e);
    }
    final Window root = (Window) vaadlets.getRoot();
    setMainWindow(root);

    final Button testButton = vaadlets.getComponent("test");
    testButton.addListener(new ClickListener() {

      @Override
      public void buttonClick(final ClickEvent event) {
        final Panel content = vaadlets.getComponent("content");
        final TextField editor = vaadlets.getComponent("editor");
        content.getContent().removeAllComponents();
        try {
          final VaadletsBuilder v = new VaadletsBuilder();
          v.build(new ByteArrayInputStream(editor.toString().getBytes()));
          if (v.getRoot() instanceof Window) {
            final Window w = (Window) v.getRoot();
            root.addWindow(w);
          } else {
            content.getContent().addComponent(v.getRoot());
          }
        } catch (final Exception e) {
          LOG.error("error", e);
          content.addComponent(createStackTraceLabel(e));
        }
      }
    });
    final Button resetButton = vaadlets.getComponent("reset");
    resetButton.addListener(new ClickListener() {

      @Override
      public void buttonClick(final ClickEvent event) {
        fillEditorWithDefaultXML(vaadlets);
      }
    });
    fillEditorWithDefaultXML(vaadlets);
  }
}
