UploadField

Extension of the Vaadin Upload component to allow usage in forms and enhance multi file uploads.

View larger

Close

Extension of the Vaadin Upload component to allow usage in forms and enhance multi file uploads.

Core class is org.vaadin.addons.thshsh.upload.UploadField. By default this class uses the com.vaadin.flow.component.upload.receivers.MultiFileBuffer receiver, which can be overridden with other receivers like so:

new UploadField(new MultiFileMemoryBuffer())

There is very little reason to use any Receiver other than MultiFileBuffer or MultiFileMemoryBuffer, as the UploadField itself supports limiting the maxFiles to 1 regardless of the underlying receiver implementation.

Features and Enhancements

• Field can be used with Binder to read/write a collection of org.vaadin.addons.thshsh.upload.UploadFile objects on an entity.
• UploadFile POJO holds all necessary properties to work with the uploaded data
• Disallow duplicate file names
• Field Value can be set on sever side even if no data has been uploaded to allow user to delete file references
• Temp Directory can be overridden
• Temp files can preserve upload file name and extension

        UploadField field = new UploadField();

        //override some defaults
        field.setAllowDuplicateNames(true); //default is false
        field.setTempDirectory(Files.createTempDirectory("mytempdir").toFile());   //default auto generates temp dir
        field.setPreserveFileNames(true); //default is false, which uses temp file names
        field.setMaxFiles(5);  //default is null (no-limit)
        field.setAutoUpload(false);  //default is true

        //Can set values without data to allow user to manipulate
        List<UploadFile> files = List.of(new UploadFile(new FileData("serverfile.txt","txt",new ByteArrayOutputStream()),null));
        field.setValue(files);

Sample code

package org.vaadin.addons.thshsh.upload;

import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.nio.file.Files;
import java.util.ArrayList;
import java.util.List;

import com.vaadin.flow.component.button.Button;
import com.vaadin.flow.component.html.Hr;
import com.vaadin.flow.component.html.Span;
import com.vaadin.flow.component.orderedlayout.VerticalLayout;
import com.vaadin.flow.component.upload.receivers.FileData;
import com.vaadin.flow.component.upload.receivers.MemoryBuffer;
import com.vaadin.flow.component.upload.receivers.MultiFileBuffer;
import com.vaadin.flow.component.upload.receivers.MultiFileMemoryBuffer;
import com.vaadin.flow.data.binder.Binder;
import com.vaadin.flow.data.binder.ValidationException;
import com.vaadin.flow.router.Route;

@Route("")
public class AddonView extends VerticalLayout {

    private static final long serialVersionUID = -5828371605864015426L;


    public AddonView() throws IOException {




        add(new Span(MemoryBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=1"));
        UploadField field = addUploadField(new UploadField(new MemoryBuffer()));

        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=4"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(4);

        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=1"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(1);

        add(new Span(MultiFileMemoryBuffer.class.getSimpleName()+", AutoUpload=false, MaxFiles=3"));
        field = addUploadField(new UploadField(new MultiFileMemoryBuffer()));
        field.setAutoUpload(false);
        field.setMaxFiles(3);


        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=4"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(4);


    }

    protected UploadField addUploadField(UploadField field) {

        Bean bean = new Bean();
        Binder<Bean> binder = new Binder<>();

        //UploadField field = new UploadField(c.getDeclaredConstructor().newInstance());
        add(field);
        binder.forField(field).bind(Bean::getFiles, Bean::setFiles);

        Span message = new Span();
        add(message);

        Button bind = new Button("Bind",click -> {
            try {
                binder.writeBean(bean);
                message.setText("Bean Files set to: "+bean.getFiles());
            }
            catch (ValidationException e) {
            }
        });
        add(bind);

        binder.readBean(bean);
        add(new Hr());

        return field;

    }

    public static class Bean {

        List<UploadFile> files;

        public Bean() {
            super();
        }

        public List<UploadFile> getFiles() {
            if(files == null) files = new ArrayList<>();
            return files;
        }

        public void setFiles(List<UploadFile> files) {
            this.files = files;
        }





    }
}
