UploadField

Extension of the Vaadin Upload component to allow usage in forms and enhance multi file uploads.

Author

Rating

Popularity

200+

Extension of the Vaadin Upload component to allow usage in forms and enhance multi file uploads.

Core class is org.vaadin.addons.thshsh.upload.UploadField. By default this class uses the com.vaadin.flow.component.upload.receivers.MultiFileBuffer receiver, which can be overridden with other receivers like so:

new UploadField(new MultiFileMemoryBuffer())

There is very little reason to use any Receiver other than MultiFileBuffer or MultiFileMemoryBuffer, as the UploadField itself supports limiting the maxFiles to 1 regardless of the underlying receiver implementation.

Features and Enhancements

  • Field can be used with Binder to read/write a collection of org.vaadin.addons.thshsh.upload.UploadFile objects on an entity.
  • UploadFile POJO holds all necessary properties to work with the uploaded data
  • Disallow duplicate file names
  • Field Value can be set on sever side even if no data has been uploaded to allow user to delete file references
  • Temp Directory can be overridden
  • Temp files can preserve upload file name and extension
        UploadField field = new UploadField();

        //override some defaults
        field.setAllowDuplicateNames(true); //default is false
        field.setTempDirectory(Files.createTempDirectory("mytempdir").toFile());   //default auto generates temp dir
        field.setPreserveFileNames(true); //default is false, which uses temp file names
        field.setMaxFiles(5);  //default is null (no-limit)
        field.setAutoUpload(false);  //default is true

        //Can set values without data to allow user to manipulate
        List<UploadFile> files = List.of(new UploadFile(new FileData("serverfile.txt","txt",new ByteArrayOutputStream()),null));
        field.setValue(files);

Sample code

package org.vaadin.addons.thshsh.upload;

import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.nio.file.Files;
import java.util.ArrayList;
import java.util.List;

import com.vaadin.flow.component.button.Button;
import com.vaadin.flow.component.html.Hr;
import com.vaadin.flow.component.html.Span;
import com.vaadin.flow.component.orderedlayout.VerticalLayout;
import com.vaadin.flow.component.upload.receivers.FileData;
import com.vaadin.flow.component.upload.receivers.MemoryBuffer;
import com.vaadin.flow.component.upload.receivers.MultiFileBuffer;
import com.vaadin.flow.component.upload.receivers.MultiFileMemoryBuffer;
import com.vaadin.flow.data.binder.Binder;
import com.vaadin.flow.data.binder.ValidationException;
import com.vaadin.flow.router.Route;

@Route("")
public class AddonView extends VerticalLayout {

    private static final long serialVersionUID = -5828371605864015426L;


    public AddonView() throws IOException {




        add(new Span(MemoryBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=1"));
        UploadField field = addUploadField(new UploadField(new MemoryBuffer()));

        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=4"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(4);

        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=1"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(1);

        add(new Span(MultiFileMemoryBuffer.class.getSimpleName()+", AutoUpload=false, MaxFiles=3"));
        field = addUploadField(new UploadField(new MultiFileMemoryBuffer()));
        field.setAutoUpload(false);
        field.setMaxFiles(3);


        add(new Span(MultiFileBuffer.class.getSimpleName()+", AutoUpload=true, MaxFiles=4"));
        field = addUploadField(new UploadField());
        field.setMaxFiles(4);


    }

    protected UploadField addUploadField(UploadField field) {

        Bean bean = new Bean();
        Binder<Bean> binder = new Binder<>();

        //UploadField field = new UploadField(c.getDeclaredConstructor().newInstance());
        add(field);
        binder.forField(field).bind(Bean::getFiles, Bean::setFiles);

        Span message = new Span();
        add(message);

        Button bind = new Button("Bind",click -> {
            try {
                binder.writeBean(bean);
                message.setText("Bean Files set to: "+bean.getFiles());
            }
            catch (ValidationException e) {
            }
        });
        add(bind);

        binder.readBean(bean);
        add(new Hr());

        return field;

    }

    public static class Bean {

        List<UploadFile> files;

        public Bean() {
            super();
        }

        public List<UploadFile> getFiles() {
            if(files == null) files = new ArrayList<>();
            return files;
        }

        public void setFiles(List<UploadFile> files) {
            this.files = files;
        }





    }
}

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Fixed NPE and issue with two mutually exclusive settings.

Released
2023-07-10
Maturity
STABLE
License
Apache License 2.0

Compatibility

Framework
Vaadin 23+
Browser
Browser Independent
