schema-diagram

Core visual component for https://github.com/SchemerApp/schemer-desktop

This component can also be the basis for an interactive visual database documentation, provided you correctly use the schema variable

<schema-diagram
                schema='[{ "name": "Table_1", "columns": [{"name": "id", "type": "integer"}, {"name": "val", "type": "string"}], "relations": ["config_table.id"]},
            { "name": "config_table", "columns": [{"name": "id", "type": "integer"}, { "name": "value", "type": "string"}], "relations": []}]'></schema-diagram>

More documentation coming soon

License

MIT
