Polymer web component for displaying a project timeline.

Simple timeline widget for Polymer

Available in Vaadin_Directory

With simple-timeline you can present a horizontal timeline of events. The event are relative left is 0 and right is 100 and vertically the titles can be set on different levels (-3 to 3). A custom item click listener can be added to make the timeline diagram interactive.

Version v1.x is targeted for Polymer 1, and v2.x is targeted for Polymer 2.

Example usage:

<simple-timeline id="mytimeline" breaks="0=Q1/2018;25=Q2;50=Q3;75=Q4 (and we should be ready)">
    <simple-timeline-item id="today" x="16" y="3">Today</simple-timeline-item>
    <simple-timeline-item x="10" y="-1">Project start</simple-timeline-item>
    <simple-timeline-item x="20" y="-2">Prototypes ready. Start collecting feedback.</simple-timeline-item>
    <simple-timeline-item class="release" x="30" y="1">Alpha1 release</simple-timeline-item>
    <simple-timeline-item class="release" x="52" y="1">Beta1 release</simple-timeline-item>
    <simple-timeline-item x="75" y="2">RC release</simple-timeline-item>
    <simple-timeline-item id="final-release" x="85" y="3">Release Date</simple-timeline-item>
</simple-timeline>

Install

Link to this version
ImportedReleased 27 March 2018MIT License
Framework Support
Polymer 2.0+
Browser Independent
Install with
bower install --save samie/simple-timeline"#2.0.0-beta"
Run the above Bower command in your project folder. If you have any issues installing, please contact the author.
Release notes - Version 2.0.0-beta

Dependencies

  • polymer#Polymer/polymer#^2.0.0
  • webcomponentsjs#webcomponents/webcomponentsjs#^1.1.0
