RichOptionGroup Add-on

OptionGroup with tooltip support for the items

Author

Rating

Popularity

<100

The Standard Vaadin Option Group does not support to show tooltips for the items of the option group.

This component extends the standard implementation by introducing two description properties for the items: DESCRIPTION_ICON -> Icon for the tooltip DESCRIPTION_TEXT -> Text for the tooltip

A demo-application is contained in the source-code-repository, see READE.md.

Sample code

/**
 * (C) Andreas Eternach 2013.
 */
package com.eternach.demo;

import com.eternach.RichOptionGroup;
import com.vaadin.annotations.Theme;
import com.vaadin.annotations.Title;
import com.vaadin.data.Item;
import com.vaadin.data.util.IndexedContainer;
import com.vaadin.server.Resource;
import com.vaadin.server.ThemeResource;
import com.vaadin.server.VaadinRequest;
import com.vaadin.ui.Alignment;
import com.vaadin.ui.UI;
import com.vaadin.ui.VerticalLayout;

@Theme("demo")
@Title("RichOptionGroup Add-on Demo")
@SuppressWarnings("serial")
public class DemoUI extends UI {

  private static final String CAPTION_ITEM_PROPERTY = "caption-item-property";

  @Override
  protected void init(final VaadinRequest request) {

    // Initialize our new UI component
    final RichOptionGroup richOptionGroup = new RichOptionGroup("Label of Option-Group");
    richOptionGroup.setItemCaptionPropertyId(CAPTION_ITEM_PROPERTY);
    richOptionGroup.setContainerDataSource(new IndexedContainer() {
      {
        addContainerProperty(CAPTION_ITEM_PROPERTY, String.class, null);
        addContainerProperty(RichOptionGroup.DESCRIPTION_TEXT, String.class, null);
        addContainerProperty(RichOptionGroup.DESCRIPTION_ICON, Resource.class, null);
        final Item value1 = addItem("value1");
        value1.getItemProperty(CAPTION_ITEM_PROPERTY).setValue("value1 Label");
        value1.getItemProperty(RichOptionGroup.DESCRIPTION_TEXT).setValue("value1 description");
        value1.getItemProperty(RichOptionGroup.DESCRIPTION_ICON).setValue(new ThemeResource("images/value1.jpg"));
        final Item value2 = addItem("value2");
        value2.getItemProperty(CAPTION_ITEM_PROPERTY).setValue("value2 Label");
        value2.getItemProperty(RichOptionGroup.DESCRIPTION_TEXT).setValue("value2 description");
        value2.getItemProperty(RichOptionGroup.DESCRIPTION_ICON).setValue(new ThemeResource("images/value2.jpg"));
      }
    });

    // Show it in the middle of the screen
    final VerticalLayout layout = new VerticalLayout();
    layout.setStyleName("demoContentLayout");
    layout.setSizeFull();
    layout.addComponent(richOptionGroup);
    layout.setComponentAlignment(richOptionGroup, Alignment.MIDDLE_CENTER);
    setContent(layout);

  }
}

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Released
2013-05-07
Maturity
STABLE
License
Apache License 2.0

Compatibility

Framework
Vaadin 7.0+
Browser
Browser Independent
