vega-element

Custom element for rendering interactive data visualization with Vega and Vega-Lite.

Author

Rating

Popularity

<100

@polymer-vis/vega-elements GitHub release Published on webcomponents.org styled with prettier Typescript

@polymer-vis/vega-elements is a suite of custom elements to render and interact with [Vega](https://vega.github.io/vega) and [Vega-Lite](https://vega.github.io/vega-lite) specifications and views.

More API documentation and Demos can be found on the web components page for vega-elements. More examples can also be found in the Github page.

Versions details
v3 is a breaking change, where the components are moved to npm, and developed in typescript and inherits from lit-element instead of polymer-element.

  • v3 Build with Typescript and inherits from Lit-Element (instead of Polymer-Element).
  • v2 Supports Polymer 2.0, Vega 3.0, and Vega-Lite 2.0
  • v1 Supports Polymer 1.0 and Vega 2.0

Components

Currently, only vega-embed is available.

@polymer-vis/vega-elements/vega-embed.js
vega-embed is a custom element that wraps around the vega-embed micro-lib.

Usage

Installation

npm i @polymer-vis/vega-elements --save

Usage in html

<vega-embed spec="/path/to/some/vega/spec.json"></vega-embed>

Usage in online code sharing hosts (e.g. jsfiddle, gist, etc)

<!-- Import Vega 4 & Vega-Lite 2 (as needed) -->
<script src="https://cdn.jsdelivr.net/npm/vega@[VERSION]"></script>
<script src="https://cdn.jsdelivr.net/npm/vega-lite@[VERSION]"></script>

<!-- Load a bundled version of vega-embed custom element with jsdelivr -->
<script src="https://cdn.jsdelivr.net/npm/@polymer-vis/vega-elements/dist/vega-embed.bundled.min.js"></script>

<vega-embed spec="/path/to/some/vega/spec.json"></vega-embed>

<script>
// create a new vega-embed element programmatically
const ele = new VegaElements.VegaEmbed();
// set attribute
ele.setAttribute("show-export", true);
// set property
ele.showSource = true;
// set some spec
ele.spec = {...};
// attach to DOM
document.body.appendChild(ele);
</script>

Usage with lit-html

// import lit-html
import {render, html} from "lit-html";

// import the vega-embed element
import "./node_modules/vega-elements/vega-embed.js";

// vega-lite specification
conse scatterplot = {
  "$schema": "https://vega.github.io/schema/vega-lite/v2.json",
  "description": "A scatterplot showing horsepower and miles per gallons for various cars.",
  "data": {"url": "data/cars.json"},
  "mark": {"type": "point", "tooltip": {"content": "data"}},
  "encoding": {
    "x": {"field": "Horsepower", "type": "quantitative"},
    "y": {"field": "Miles_per_Gallon", "type": "quantitative"},
    "tooltip": [
      {"field": "Horsepower", "type": "quantitative"},
      {"field": "Miles_per_Gallon", "type": "quantitative"}
    ]
  }
};

// create the factory method to create a html template result
const embedTmpl = (spec, opts) => html`<vega-embed spec=${spec} opts=${opts}></vega-embed>`;

// render the template result to document body
render(embedTmpl(scatterplot, {tooltip: true, renderer: "canvas"}), document.body);

UMD bundles

vega-elements provides 2 pre-build UMD distributions (under the named scope VegaElements) for vega-embed custom element.

  • ./dist/vega-embed.min.js: Minimal bundle with only @polymer/lit-element and @polymer-vis/vega-elements. Vega, Vega-Lite, and vega-embed should be imported separately.

  • ./dist/vega-embed.bundled.min.js: Bundle with @polymer/lit-element, vega-embed, and @polymer-vis/vega-elements. Vega or/and Vega-Lite should be imported separately.

Disclaimer

PolymerVis is a personal project and is NOT in any way affliated with Vega, Vega-Lite, Polymer or Google.

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Dependencies

  • @polymer/lit-element#^0.6.1
  • @polymer/polymer#^3.1.0
  • vega-embed#^3.18.2
Released
2018-10-29
Maturity
IMPORTED
License
MIT License

Compatibility

Framework
Polymer 3.0+
Polymer 2.0+ in 2.0.3
Polymer 1.0+ in 1.0.5
Browser
Browser Independent
