granite-inspector
A lit-element based version of react-inspector
<granite-inspector>
A custom element, lit-element based, version of react-inspector
Power of Browser DevTools inspectors right as a custom element.
� Status: In Development
granite-inspector
is currently in development. We encourage you to use it and give us your feedback, but there are things that haven't been finalized yet and you can expect some changes.
Usage example
<granite-object-inspector data='["a", "b", { "c": "d", "e": "f", "g": { "h": "i", "j": "k"}}]'></granite-object-inspector>
Install
Install the component using npm:
$ npm i @granite-elements/ace-widget --save
Once installed, import it in your application:
import '@granite-elements/ace-widget/ace-widget.js';
Running demos and tests in browser
Fork the
ace-widget
repository and clone it locally.Make sure you have npm and the Polymer CLI installed.
When in the
ace-widget
directory, runnpm install
to install dependencies.Serve the project using Polyumer CLI:
polymer serve --module-resolution node --component-dir node_modules
Open the demo in the browser
Elements
<granite-inspector />
A shorthand for the inspectors.
<granite-inspector/>
is currently equivalent to<granite-inspector-object>
- DOM and table mode are under active development
<granite-inspector-object />
Like console.log
. Consider this as a glorified version of <pre>JSON.stringify(data, null, 2)</pre>
.
How it works
Tree state is saved at root. If you click to expand some elements in the hierarchy, the state will be preserved after the element is unmounted.
API
The component accepts the following props:
data {Object}
: the Javascript object you would like to inspect
name {String}
: specify the optional name of the root node, default to undefined
expandLevel {Number}
: an integer specifying to which level the tree should be initially expanded.
expandPaths {String|Array}
: an array containing all the paths that should be expanded when the component is initialized, or a string of just one path
- The path string is similar to JSONPath.
- It is a dot separated string like
$.foo.bar
.$.foo.bar
expands the path$.foo.bar
where$
refers to the root node. Note that it only expands that single node (but not all its parents and the root node). Instead, you should useexpandPaths={['$', '$.foo', '$.foo.bar']}
to expand all the way to the$.foo.bar
node. - You can refer to array index paths using
['$', '$.1']
- You can use wildcard to expand all paths on a specific level
- For example, to expand all first level and second level nodes, use
['$', '$.*']
(equivalent toexpandLevel={2}
)
- For example, to expand all first level and second level nodes, use
- It is a dot separated string like
- the results are merged with expandLevel
showNonenumerable {Boolean}
: show non-enumerable properties.
sortObjectKeys {Boolean|Function}
: Sort object keys with optional compare function.
nodeRenderer {Function}
: Use a custom nodeRenderer
to render the object properties (optional)
Instead of using the default
nodeRenderer
, you can provide a custom function for rendering object properties. The default nodeRender looks like this:import './granite-inspector-object-label'; import './granite-inspector-object-root-label'; const defaultNodeRenderer = ({ depth, name, data, isNonEnumerable }) => { return html` ${depth === 0 ? html`<granite-inspector-object-root-label name=${name} data=${data}></granite-inspector-object-root-label>` : html` <granite-inspector-object-label name=${name} data=${data} isNonEnumerable=${isNonEnumerable}></granite-inspector-object-label>` } `; };
Theme
By specifying the theme
prop you can customize the inspectors. theme
prop can be
- a string referring to a preset theme (
"chromeLight"
or"chromeDark"
, default to"chromeLight"
) - or a custom object that provides the necessary variables. Checkout
src/styles/themes
for possible theming variables.
Example 1: Using a preset theme:
<granite-inspector theme="chromeDark" data='{"a": "a", "b": "b"}'></granite-inspector>
Roadmap
Type of inspectors:
- Tree style
- common objects
- DOM nodes
- Table style
- Column resizer
- Group style
Contributing
- Fork it!
- Create your feature branch:
git checkout -b my-new-feature
- Commit your changes:
git commit -m 'Add some feature'
- Push to the branch:
git push origin my-new-feature
- Submit a pull request :D
