HTML Dialog

Vaadin Flow integration of the html <dialog> element.

Description

This addon provides a Java integration for Flow to work with an html dialog. It allows you to create a simple dialog, that is mostly handled by the browser.

Also see https://developer.mozilla.org/en-US/docs/Web/API/HTMLDialogElement for additional information.

Features

  • dialog can be shown as normal or modal variant
  • support of adding any type of Vaadin components
  • automatic activation of Flow's server side modality feature
  • Java api for "no close on escape" and "autofocus"
  • Java events for "opened" / "closed" events
  • auto attachment to and detachment from the UI, when necessary (see Javadocs on the show methods)
  • no additional stylings or contents. No shadow dom or similar.

Examples

Creating a simple dialog

Dialog dialog = new Dialog();
dialog.add(...); // add some context, e.g. span, buttons, or similar.

Open the dialog in the UI

In this scenario, the dialog is automatically attached to the current UI, when one of the show methods are called. When closed, the dialog is also automatically detached.

Dialog dialog = new Dialog();
// add content

dialog.show(); // shows the dialog as a non modal dialog, auto attaches it to the current UI.

// or call instead
dialog.showModal(); // shows the dialog as a modal dialog, auto attaches it to the current UI.

someButton.addClickListener(event -> dialog.close()); // closes the dialog and detaches it from the UI

Open the dialog "inside" another component

In this scenario, the dialog is manually attached to a container (e.g. the current view). It is not detached automatically - this has to be done by you. Please be advised, that the dialog is only detached automatically, when it's containing element is detached.


Dialog dialog = new Dialog();
// add content

container.add(dialog);

dialog.show(); // shows the dialog as a non modal dialog, attached to the "container".

// or call instead
dialog.showModal(); // shows the dialog as a modal dialog, attached to the "container".

someButton.addClickListener(event -> dialog.close()); // just closes the dialog, does NOT automatically detach it

No close on escape

By default a modal dialog is closed, when the user presses the "Escape" key. This can be prevented by using the withoutCloseOnEsc method. Non modal dialogs never close on escape, so in that case, calling that method is not necessary.

dialog.withoutCloseOnEscape().showModal(); // needs to be closed using some interactive element, e.g. a button

Autofocus on open

To have a better UX, you may autofocus the dialog, when shown.

dialog.withAutofocus().show(); // or showModal();

Server side modality

Vaadin provides a mechanism to prevent the client from circumventing the modality by blocking any requests for components, that are not a child of the current modal container. This mechanism is also used for the dialog, when shown modal.

If you need or want to disable this mechanism, you can do that by easily call withoutModalServerSide before showing the dialog. It still will be shown modal in the client, but Vaadin will not block any events for components outside the modal container.

dialog.withoutModalServerSide().showModal();

Event handling

The component provides two event types to register for.

dialog.addOpenedListener(event ->
        Notification.show("Dialog has been opened " + (event.isModal() ? "modal" : "modeless")));

        dialog.addClosedListener(event ->
        Notification.show("Dialog has been closed " + (event.isClosedByEscape() ? "by the Escape key" : "somehow")));

Technical side note: These events are not the native browser events, since the dialog element does not provide an "open" event and the "close" event will not be always fired correctly (for instance when the component is detached from the dom).

Also, the opened event will always be triggered by the client side. The close event itself may be triggered by the client or server side. Due to the manual handling of the close event, there is an additional close method, that allows to simulate a client side close for the sake of the event source. However, that method should only be called by other event handlers.

// calling Dialog#close(boolean) allows setting the isFromClient flag for the ClosedEvent
new Button("Close", event -> dialog.close(event.isFromClient()));

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Released
2024-01-19
Maturity
STABLE
License
Apache License 2.0

Compatibility

Framework
Vaadin 24+
Browser
Firefox
Opera
Safari
Google Chrome
iOS Browser
Android Browser
Microsoft Edge
