FormBuilders

FormBuilder - tool for build form through annotations in model class

Author

Rating

Popularity

<100

-Using annotation to build form -Simple validation -Set fields width for all form -Can build couple forms basic on single object -Can build form with relation -Disable selected fields -List and multiselect -Build any Object extends com.vaadin.ui.AbstractComponent

Extension use default vaadin itembinder to bind object

More deep documentation and help on github

Sample code

	@Override
	protected void init(VaadinRequest request) {
		final VerticalLayout layout = new VerticalLayout();
		layout.setMargin(true);
		setContent(layout);

		//Create formbuilder object with empty User object
		FormBuilder<User> fb = new FormBuilder<User>(User.class, new User());

		//Set field width for all fields
		fb.setFieldWidth(300, Unit.PIXELS);

		//Builds two separate forms through name
		HorizontalLayout hl = new HorizontalLayout(fb.buildForm(),fb.buildForm(FormName.COL2));
		layout.addComponent(hl);
		layout.addComponent(new Button("Save",e->saveItem(fb)));

		//Add external listener for field
		((TextField)fb.getField("street")).addValueChangeListener(e->eventChange(e));

		//Set disabled fields and rebuild form
		fb.setDisableField(Arrays.asList("city"));
		fb.refreshForm();

	}
	private void eventChange(ValueChangeEvent e) {
		Notification.show("Street was change");
	}

	private void saveItem(FormBuilder<User> fb) {
		if(fb.validAndCommit()){
			User saved = fb.getItemDataSource();
			Notification.show("Item was saved");
		}else{
			Notification.show("Fill form first");
		}
	}
public class User {

	public User(){
		this.group=new Group(); //every object in form can't be null
	}
	@FormField
	@Nullable(message="Can not be empty",value=false)
	private String name;
	@FormField
	@Regex(message="must contains rr",regex=".*rr.*")
	@Nullable
	private String surname;
	@FormField
	private int age;
	@FormField
	private Date brithday;
	@FormField("Another field name")
	private BigDecimal price;
	@FormField(name="Discription",type=FieldType.TEXTAREA)
	private String discription;
	@FormField(name="password",disable=true)
	private String password;

	@FormField(name="Street",formName=FormName.COL2)
	private String street;
	@FormField(name="City",formName=FormName.COL2)
	private String city;
	@FormField(name="Code",formName=FormName.COL2)
	private String code;

	@InnerForm
	private Group group;

	private Group group2;

	/**   Getters and Setters - must exists **/
}
public class Group {

	@FormField("group name")
	private String name;

	@FormField("description")
	private String description;

        public String getName() {
		return name;
	}
	public void setName(String name) {
		this.name = name;
	}
	public String getDescription() {
		return description;
	}
	public void setDescription(String description) {
		this.description = description;
	}
}
public class Form{
       	@FormField(value="Group select",componentClass=GroupListSelectGroup.class)
	private Group group;

	public Group getGroup() {
		return group;
	}

	public void setGroup(Group group) {
		this.group = group;
	}
}

public class GroupListSelectGroup extends ComboBox{

	public GroupListSelectGroup() {
		super("Grupy", createExampleDataSource());
		setItemCaptionPropertyId("NAME");

	}
	@SuppressWarnings("unchecked")
	private static Container createExampleDataSource() {
		Container ct = new IndexedContainer();
		ct.addContainerProperty("NAME", String.class, "");
		Group c = new Group(1l,"First");
		Item it = ct.addItem(c);
		it.getItemProperty("NAME").setValue(c.getDescription());
		Group cc = new Group(2l,"Second");
		it = ct.addItem(cc);
		it.getItemProperty("NAME").setValue(cc.getDescription());
		return ct;
	}
}
public class Form{
	@FormField(value="grupy",componentClass=GroupListSelectLong.class)
	private Set<Long> groupIds;
	public Set<Long> getGroupId() {
		return groupId;
	}

	public void setGroupId(Set<Long> groupId) {
		this.groupId = groupId;
	}
}

public class GroupListSelectLong extends ListSelect{

	public GroupListSelectLong() {
		super("Grupy", createDataSource());
		setItemCaptionPropertyId("NAME");
		setMultiSelect(true);
	}

	private static Container createDataSource() {
		Container ct = new IndexedContainer();
		ct.addContainerProperty("NAME", String.class, "");
		Group c = new Group(1l,"First");
		Item it = ct.addItem(c.getId());
		it.getItemProperty("NAME").setValue(c.getDescription());
		Group cc = new Group(2l,"Second");
		it = ct.addItem(cc.getId());
		it.getItemProperty("NAME").setValue(cc.getDescription());
		return ct;
	}
}
FormBuilder<User> fb = new FormBuilder<User>(User.class, new User());
layout.addComponent(fb.buildForm());

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

  • Add new construct to class FormBuilder with param boolean called superClass. This provides creating fields from parent class.
  • Fixed bug with creating InnerForm in layer deeper than 2
Released
2016-07-14
Maturity
STABLE
License
Apache License 2.0

Compatibility

Framework
Vaadin 7.0+
Browser
Browser Independent

FormBuilders - Vaadin Add-on Directory

FormBuilder - tool for build form through annotations in model class FormBuilders - Vaadin Add-on Directory
-Using annotation to build form -Simple validation -Set fields width for all form -Can build couple forms basic on single object -Can build form with relation -Disable selected fields -List and multiselect -Build any Object extends com.vaadin.ui.AbstractComponent Extension use default vaadin itembinder to bind object More deep documentation and help on github
Author Homepage
Issue Tracker
Source Code

FormBuilders version 1.0.1
null

FormBuilders version 1.0.2
-Add auto build any component extends Field. ListSelect, ComboBox etc. -Config width for sinlge fields

FormBuilders version 1.0.4
-Fixed widgestes compilation bug from version 1.0.3. -Use name for component from annotation as primary

FormBuilders version 1.0.5
- Add new construct to class FormBuilder with param boolean called superClass. This provides creating fields from parent class. - Fixed bug with creating InnerForm in layer deeper than 2
