FontIcon

Easily use scalable font icons (from the excellent Font Awesome) with Vaadin

View larger

Close

Note that Vaadin comes with built-in FontIcon support since 7.2, making this version redundant. Look out for future updates!

FontIcon makes it super-simple to use scalable font icons in your Vaadin application. No widgetset recompile or theme modifications are required to get up-and-running; by default FontIcon loads the icons from a CDN (you can add the icons to your theme if you prefer).

The icon font currently supported is Font Awesome, the iconic font designed for use with Twitter Bootstrap.

Note that the regular Vaadin setIcon() etc is currently not supported, since an icon-font is not a Resource. Instead, the icons can be added anywhere where HTML is allowed, such as Button captions, Labels, tooltips etc. Just remember to enable HTML content (e.g Button.setHtmlContentAllowed(true)).

As the icons are actually text, they will adjust to the size, color, etc of the containing text. In addition, all the icons have a number of variants.

By default (when using FontAwesome.load()) the CSS and font is loaded from an online CDN, but you can host the font yourself. Just download Font Awesome and add it to your theme, then load it like so: FontAwesome.load(new ThemeResource("font-awesome/css/font-awesome.min.css"));

You can also create an optimized font with just the icons you need; for instance IconMoon is a service that makes that super easy.

The FontIcon code is Apache 2, while Font Awesome pictograms use CC BY 3.0 (no attribution required) and the actual font SIL Open Font License (see link for more info).

Sample code

FontAwesome.load();

Button button = new Button(Icon.thumbs_up + " Click Me");
button.setHtmlContentAllowed(true);

// If you unzipped Font Awesome to a "font-awesome" folder in your theme:
FontAwesome.load(new ThemeResource(
                "font-awesome/css/font-awesome.min.css"));

package org.vaadin.fonticon;

import java.util.Arrays;
import java.util.Set;

import com.porotype.iconfont.FontAwesome;
import com.porotype.iconfont.FontAwesome.Icon;
import com.porotype.iconfont.FontAwesome.IconVariant;
import com.vaadin.data.Property.ValueChangeEvent;
import com.vaadin.data.Property.ValueChangeListener;
import com.vaadin.server.VaadinRequest;
import com.vaadin.shared.ui.label.ContentMode;
import com.vaadin.ui.AbstractSelect;
import com.vaadin.ui.Button;
import com.vaadin.ui.ComboBox;
import com.vaadin.ui.CssLayout;
import com.vaadin.ui.HorizontalLayout;
import com.vaadin.ui.Label;
import com.vaadin.ui.NativeButton;
import com.vaadin.ui.TwinColSelect;
import com.vaadin.ui.UI;
import com.vaadin.ui.VerticalLayout;
import com.vaadin.ui.themes.Reindeer;

/**
 * Main UI class
 */
@SuppressWarnings("serial")
public class FonticonUI extends UI {

    Label demoLabel;
    Button demoButton;
    NativeButton demoNativeButton;

    @Override
    protected void init(VaadinRequest request) {
        FontAwesome.load(); // REMEMBER to load!

        // Main layout
        final VerticalLayout layout = new VerticalLayout();
        layout.setSpacing(true);
        layout.setMargin(true);
        setContent(layout);

        // Intro label w/ various icons
        Label label = new Label(
                Icon.info_sign.variant(IconVariant.PULL_LEFT,
                        IconVariant.SIZE_4X)
                        + "This demonstrates some of the use-cases for font icons in Vaadin.<br/>"
                        + Icon.warning_sign
                        + " Please note that a font-icon is not a <code>Resource</code>, and can not be used as a"
                        + " regular Vaadin icon using <code>setIcon()</code>.<br> Instead, you can add a font-icon anywhere "
                        + Icon.exclamation_sign
                        + " where you can use formatted HTML, including tooltips.",
                ContentMode.HTML);
        layout.addComponent(label);

        // Playground
        HorizontalLayout hz = new HorizontalLayout();
        hz.setSpacing(true);
        hz.setCaption("Icon playground");
        layout.addComponent(hz);
        // Icon/variant selects
        VerticalLayout vl = new VerticalLayout();
        vl.setStyleName(Reindeer.LAYOUT_BLUE);
        vl.setMargin(true);
        hz.addComponent(vl);
        final ComboBox icon = new ComboBox("Icon", Arrays.asList(Icon.values())) {
            @Override
            public String getItemCaption(Object itemId) {
                // format the caption in the combobox
                return ((Icon) itemId).name();
            }
        };
        vl.addComponent(icon);
        icon.setNullSelectionAllowed(false);
        icon.setImmediate(true);
        final TwinColSelect variant = new TwinColSelect("Variant(s)",
                Arrays.asList(IconVariant.values()));
        variant.setImmediate(true);
        vl.addComponent(variant);
        // Demo components
        vl = new VerticalLayout();
        vl.setSpacing(true);
        hz.addComponent(vl);
        demoLabel = new Label("", ContentMode.HTML); // REMEMBER ContentMode
        vl.addComponent(demoLabel);
        demoButton = new Button();
        demoButton.setHtmlContentAllowed(true); // REMEMBER HtmlAllowed
        vl.addComponent(demoButton);
        demoNativeButton = new NativeButton();
        demoNativeButton.setHtmlContentAllowed(true); // REMEMBER HtmlAllowed
        vl.addComponent(demoNativeButton);
        // listeners
        icon.addValueChangeListener(new ValueChangeListener() {
            @Override
            public void valueChange(ValueChangeEvent event) {
                setDemoText(icon, variant);
            }
        });
        variant.addValueChangeListener(new ValueChangeListener() {
            @Override
            public void valueChange(ValueChangeEvent event) {
                setDemoText(icon, variant);
            }
        });
        icon.select(Icon.adjust);

        // ALL the icons
        final CssLayout icons = new CssLayout();
        icons.setCaption("ALL THE THINGS!!!");
        layout.addComponent(icons);
        for (Icon i : Icon.values()) {
            Button b = new Button(i + " " + i.name());
            b.setHtmlContentAllowed(true);
            icons.addComponent(b);
            b.setDescription(i + " " + i.name());
        }

    }

    private void setDemoText(AbstractSelect icon, AbstractSelect variant) {
        Set<IconVariant> variants = (Set<IconVariant>) variant.getValue();
        String s = ((Icon) icon.getValue()).variant(variants
                .toArray(new IconVariant[] {}));

        demoLabel
                .setValue(s
                        + " The quick brown fox jumps over the lazy dog.<br/>The quick brown fox jumps over<br/> the lazy dog.");
        demoLabel.setDescription(s + " Demo tooltip");
        demoButton.setCaption(s + " Button");
        demoButton.setDescription(s + " Demo tooltip");
        demoNativeButton.setCaption(s + " Native Button");
        demoNativeButton.setDescription(s + " Demo tooltip");
    }

}
