DatabaseVisualizer Add-on

UI Widget to visualize a relational database

View larger

Close

Vaadin widget wrapper around a Polymer Webcomponent element to help visualize a relational database.

Sample code

DatabaseVisualizer visualizer = new DatabaseVisualizer();

DatabaseVisualizerSchema schema = new DatabaseVisualizerSchema();
schema.setId(1L);
schema.setName("schema");
schema.addTable(table1);
schema.addTable(table2);

DatabaseVisualizerDatabase database = new DatabaseVisualizerDatabase();
database.addSchema(schema);

visualizer.setDatabase(database);
