Coverflow Add-on

Animated coverflow-style image gallery component

Author

Rating

Popularity

<100

The Coverflow component is an animated image gallery which uses CSS3 3D effects of the jQuery Flipster Addon (https://github.com/drien/jquery-flipster).

Features:

  • 3D CSS effects
  • imageSelectionListener fires in every client-side navigation
  • adjust max image size
  • this add-on loads jquery-1.11.2.min.js

Known issues:

  • The CoverFlow#maxSize() method accepts values bigger than the actual available space of the element on client side. This causes the images to be that large that the images are (a) larger than the coverflow component itself and (b) navigation may not be possible because the main image covers the next right image. It is planned to change this behavior in a future release.
  • Mixing images with different aspect ratios may also cause space and navigation problems so far

Roadmap:

  • set the selected image element from server side
  • add image click listener
  • optimize rendering size of the images (maybe automate it to a percentage value)

Sample code

// create url list
final List<String> imgUrls = new ArrayList<String>();
// fill list with http URLs

// Initialize the coverflow
final CoverFlow coverFlow = new CoverFlow(imgUrls);
coverFlow.setCoverflowStyle(CoverflowStyle.CAROUSEL);
coverFlow.setMaxImageSize(300);

layout.addComponent(coverFlow);
// add image selection listener
coverFlow.addImageSelectionListener(
	new ImageSelectionListener() {

		@Override
		public void onImageSelection(final ImageSelectionEvent event) {
			Notification.show("Selected Element: " + event.getSelectedIndex() + " " + event.getUrl());
		}

	};

);

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Initial version

Released
2015-04-25
Maturity
BETA
License
MIT License

Compatibility

Framework
Vaadin 7.4+
Browser
Firefox
Opera
Safari
Google Chrome
Internet Explorer
Internet Explorer
Internet Explorer
