ChartJs add-on for Vaadin 14+

ChartJS for Vaadin 14

Author

Rating

Popularity

400+

This is a Vaadin 14 compatible fork of the old ChartJS add-on which provided a fluid Java API with which users could generate ChartJS charts. More info at https://github.com/rudiejd/vaadin-chartjs.

This is currently an alpha version. Not all features from the Vaadin 8 version have been re-implemented, and some have been intentionally deprecated. Check out the README.md on this add-on's Github page for more information.

Sample code

BarChartConfig config = new BarChartConfig();
config
    .data()
        .labels("January", "February", "March", "April", "May", "June", "July")
        .addDataset(new BarDataset().type().label("Dataset 1").backgroundColor("rgba(151,187,205,0.5)").borderColor("white").borderWidth(2))
        .addDataset(new LineDataset().type().label("Dataset 2").backgroundColor("rgba(151,187,205,0.5)").borderColor("white").borderWidth(2))
        .addDataset(new BarDataset().type().label("Dataset 3").backgroundColor("rgba(220,220,220,0.5)"))
        .and();

config.
    options()
        .responsive(true)
        .title()
            .display(true)
            .position(Position.LEFT)
            .text("Chart.js Combo Bar Line Chart")
            .and()
       .done();

List<String> labels = config.data().getLabels();
for (Dataset<?, ?> ds : config.data().getDatasets()) {
    List<Double> data = new ArrayList<>();
    for (int i = 0; i < labels.size(); i++) {
        data.add((double) (Math.random() > 0.5 ? 1.0 : -1.0) * Math.round(Math.random() * 100));
    }

    if (ds instanceof BarDataset) {
        BarDataset bds = (BarDataset) ds;
        bds.dataAsList(data);
    }

    if (ds instanceof LineDataset) {
        LineDataset lds = (LineDataset) ds;
        lds.dataAsList(data);
    }
}

ChartJs chart = new ChartJs(config);
chart.setJsLoggingEnabled(true);

return chart;

Compatibility

(Loading compatibility data...)

Was this helpful? Need more help?
Leave a comment or a question below. You can also join the chat on Discord or ask questions on StackOverflow.

Version

Released
2023-12-15
Maturity
EXPERIMENTAL
License
MIT License

Compatibility

Framework
Vaadin 10+
Browser
N/A
