Custom Element that can apply functional renderers like lit-html to the vicinity of the markup.

<xtal-method>

A significant subset of the web development community is enamored with the concept of bringing the power of server-side templating engines, combined with functional concepts, to the client. But which of the competing templating engines to use? I like the approach adopted by Skate

For this reason, Skate provides a hook to inject renderers for any view library

<xtal-method> adopts the same philosophy, but sets its aim much lower (and is ultimately helping with a different problem). It views itself as a helper element web component, similar in concept to <dom-if> or <dom-repeat> or <iron-list>, but where the expression syntax has the full breadth of ES6+ JavaScript (which doesn't currently include JSX, but does include the letter h). For example, it allows you to define the markup based on (tagged) literal templates.

xtal-method is a ~777B gzipped and minified, dependency free web component.

With <xtal-method>, one pairs up an input JavaScript object with a functional renderer, and their offspring is HTML (or SVG). The output of the transformation becomes a child of the element.

<xtal-method> only has two key, required properties for anything to happen: input and renderer.

As the input property of <xtal-method> is established and then changes, the renderer generates the html output, and inserts it inside the <xtal-method> element instance, or updates the same target element as the input property changes.

The renderer property of <xtal-method> is of type function, a function that takes two arguments -- an object or array which needs to be presented, and a formatter function that generates a DOM (or SVG) node tree. The renderer property can be passed to the element instance via traditional binding:

Polymer notation:

    <xtal-method input="[[todos]]" renderer="[[todoFormatter]]"></xtal-method>

JSX:notation:

    <xtal-method input={this.todos} renderer={this.todoFormatter}></xtal-method>

It would be very wrong to ask why JSX would use a custom element to render a property. Very wrong indeed.

xtal-method has another property/attribute, "disabled" that allows the rendering to be delayed. The most obvious reason for supporting this is to prevent rendering when it isn't needed -- for example, if the element is currently hidden. Later I will discuss another potentially important reason why I think this could be useful.

Inline Markup

Keeping the markup simple, as shown above, where the renderer function is passed in as a property, will work just fine, except it will force the developer to go on a bit of a scavenger hunt to find where the renderer was set. The option to define the formatter inline, as shown below, is meant to eliminate that nuisance.

This package also contains a second custom element, xtal-im-ex, which allows us to define the renderer (and even the input) inline.

For example, here we see an untagged literal template, with no helper library, being used to set the innerHTML of the element:

        <xtal-im-ex input="[[todos]]">
            <script nomodule>
                const todoFormatterVulnerableToSecurityHacks = items => `
                Generated with no helper library:<br>
                <ul>
${items.map(item => `
                    <li>${item.value}</li>
`).join('')}
                </ul>
                `
                export const renderer = (list, target) => {
                target.innerHTML = todoFormatterVulnernableToSecurityHacks(list);
                }
            </script>
        </xtal-im-ex>


It is an 800B (gzipped and minified) dependency free web component.

NB: Code like what is shown above is quite vulnerable to hacking, especially if you can't trust the source of the data in your todo list. If the todo list changes frequently, performance will be sub optimal, at least with current browsers, and it wouldn't integrate nicely with modern binding frameworks. If these features aren't critical at first (e.g. during the initial prototyping), then it should be possible to switch to one of the more robust solutions mentioned below when the time is right (ideally before it goes to production) witout many changes.

Almost certainly you will want to use a library where such issues are thought through, like lit-html or hyperHTML.

For example let's see how we can use lit-html to render the to-do list example from the lit-html link above.

<xtal-im-ex input="[[todos]]">
    <script nomodule>
        const root = 'http://cdn.jsdelivr.net/npm/lit-html/';
        const { repeat } = await import(root + 'lib/repeat.js');
        const { html, render } = await import(root + 'lit-html.js');
        const todoFormatter = items => html`
            <h1>My Todos</h1>
            <ul>
${repeat(items, item => item.id,  item => html`
                <li class="${item.done ? 'done' : ''}">${item.value}</li>
`)}
            </ul>
        `;
        export const renderer = (list, target) => render(todoFormatter(list), target);

    </script>
</xtal-im-ex>


The script tag inside the <xtal-inline-method> allows us to specify these two properties (and more discussed below) via the export const = syntax. I.e. all the export const's inside the script tag are used to set properties of the parent element instance, <xtal-inline-method> So you could, if you want, not just specify the renderer property, but you could also set the initial input property in the same way. This allows the server to pass the original state as part of the document. This might be useful for the first paint display, and then the input property of the custom element can change based on ajax calls prompted by user actions for subsequent renders:

<xtal-im-ex>
    <script type="module ish">
        const root = 'https://cdn.jsdelivr.net/npm/lit-html/';
        const { repeat } = await import(root + 'lib/repeat.js');
        const { html, render } = await import(root + 'lit-html.js');
        const todoFormatter = items => html`
            <h1>My Todos</h1>
            <ul>
${repeat(items, item => item.id,  item => html`
                <li class="${item.done ? 'done' : ''}">${item.value}</li>
`)}
            </ul>
        `;
        export const renderer = (list, target) => render(todoFormatter(list), target);

        //server-side generated?
        export const input = [
            { "id": 1, "value": "Sweep the floor", "done": false },
            { "id": 2, "value": "Prepare fancy salad", "done": true },
            { "id": 3, "value": "Get a funky haircut", "done": false }
        ]
    </script>
</xtal-im-ex>

Another approach to server-side generated content is discussed farther down.

Boilerplate Busting with Script inserts

There will tend to be some amount of repetition between instances of this web component, assuming the same rendering library is used more than once.

In particular, the import statements will be the first candidate for sharing.

To share fragments of Javascript, define each shareable fragment within a script tag with a unique id:

  <script nomodule id="_root_lit_html">
    const root = 'https://cdn.jsdelivr.net/npm/lit-html/';
  </script>
  <script nomodule id="_lit_html">
      const { html, render } = await import(root + 'lit-html.js');
  </script>
  <script nomodule id="_lit_repeat">
    const { repeat } = await import(root + 'lib/repeat.js');
  </script>

Placing these in one central location, perhaps in the header of index.html (if applicable) seems like a pattern to adopt.

And then reference it as follows:

<xtal-im-ex input="[[todos]]">
    <script type="module ish">
        XtalIMEX.insert(_root_lit_html, _lit_html, _lit_repeat);
        const todoFormatter = items => html`
            <h1>My Todos</h1>
            <ul>
${repeat(items, item => item.id,  item => html`
                <li class="${item.done ? 'done' : ''}">
                    ${item.value}
                </li>
`)}
            </ul>
        `;
        export const renderer = (list, target) => render(todoFormatter(list), target);
    </script>
</xtal-im-ex>

Note the static method call: XtalIMEX.insert. This inserts the inner text of the script tags with the id's _root_lit_html, _lit_html, _lit_repeat defined in the header above.

Adoption Services

I think there's another significant reason this kind of inline "markup" could be of use, when combined with the disabled property mentioned earlier. And that has to do with how light children behave when they get slotted into shadow DOM. Normally, these children are treated quite differently compared to the Shadow DOM defined within the component. Sort of like being a son-in-law or daughter-in-law, where you still act polite in front of each other (usually). And that difference has many benefits. But there are some scenarios, I believe, where one really wants the children to be treated exactly as if they were part of the component itself -- i.e. getting fully adopted. Examples are wanting the children to be styled like the rest of the children inside the Shadow DOM, emittting events the Shadow DOM children can hear, etc.

If we place the inline code inside a light child, like this:

<my-component>
    <xtal-im-ex input="[[todos]]" disabled >
        <script type="module ish">
        ...
        </script>
    </xtal-im-ex>
</my-component>

Then my-component can be coded in such a way that it will "enable" its light children after being slotted, and "poof", the children are now directly added to the shadow DOM, if we allow xtal-im-ex to be passed the target (the Shadow DOM).

In particular xtal-im-ex has a property "target" which can be passed a DOM element inside the ShadowDOM where the output should render.

Note that in this scenario, the input property can still be passed new data even after the slotting takes place.

Server-side rendering of initial paint

By default, <xtal-method> dynamically creates a div element with attribute role="target" as the rendering target, and appends it inside the <xtal-method> tag. This serves as the target element for where to dump the html (or svg) each time the input changes.

However, it may be desirable to improve the time to first paint by generating the initial HTML on the server, and not providing any input object initially, until user interaction requires an update.

In this case, during design time, or when dynamically generating the HTML document, insert the initial html as another inner element within the <xtal-method>, starting from a single root tag. The root tag of that html should have attribute role="target" (and doesn't have to be a div).

How does this work, and why should I care?

Because this component manipulates the text of the script tag a bit, and then does an eval, there is a slight performance hit. The performance hit from eval seems surprisingly small. Perhaps the more significant (but still slight) overhead is in applying regular expression / string searches / replaces on the JavaScript code. Note that we are not doing any full parsing of the JavaScript. We're leaving that for the browser.

Hopefully the benefits in terms of developer productivity outweigh the performance cost (and of course, this needs to be compared to other ways of using functional renderers).

Still, if this performance is a concern, a build process could be established to do that string manipulating during the build / optimization process. Anyway, such a process is also needed to support downstream browsers that don't support dynamic import or ES6.

More on this topic to come.

Inverse Functional derendering

If SSR is used, and the initial state needs to be something that other components can bind to, typically this would require sending both the formatted HTML and the JSON from which the HTML was derived down the wire. That's an unfortunate hit on performance.

So two additional features are defined for eliminating this performance hit: reverse-render and the init-state-changed event.

derender is a property of type function. The user specifies a function, which will take the rendered (first paint) html (or svg) and "reverse engineer" the markup, by extracting out the data and turning it into a plain old JavaScript object, which when applying the renderer function would produce the same results. Mathematically, it is the "inverse" of the renderer function. The result of applying the derender function is broadcast as a custom event with name "init-state-changed," which hosting web components (Polymer being a prime example here) can listen for and bind to. The markup can look like this:

<xtal-method input="[[todos]]" init-state="{{originalTodoList}}">
    <xtal-import-export>
    <script nomodule>
        export const derenderer = (serverSideGeneratedHtml) =>{
            const todos = [];
            serverSideGeneratedHTML.querySelectorAll('li').forEach(liEl =>{
                const todo = {
                    value = liEl.innerText
                };
                todos.push(todo);
            });
            return todos;
        }
    </script>
    </xtal-import-export>
<xtal-method>

When xtal-method is passed the input object, it checks if it is the same as the init-state object. If it is, it deletes the init-state property, but doesn't rerender.

Esoteric arm-chair musings. Take with a grain of salt, i.e. ignore

Be aware, however, that there are two distinct ways this feature can be used, and the developer should have a very clear view of what scenario applies to them.

Scenario 1. Non cacheable index.html

I suspect this scenario is rare in practice, but who knows? Let's say you are a news site, like CNN, highly fluid content, maybe you insist 99% of the content should work without JavaScript. (They don't really do this. The stories are in fact encoded in JSON data, not directly in the html. If you disable JavaScript, you'll see what I mean. On the other hand, Fox News seems to be 100% HTML. Are conservatives more progressive?) It might stand to reason, then, that the root url should map to a non cacheable index.html, which isn't a file, but a dynamic stream generated by something like node/express or asp.net or a servlet or php or ... you get the idea.

Suppose now that you want to have the ability to update certain headlines, or photo captions on the fly. This would mean that an efficient (re)rendering function / derendering function may be useful.

In this case, including the renderer / derendering function inline, in index.html would be wasteful, as it won't be able to be cached. So it would be better to use the "traditional" approach mentioned earlier:

    <html>
        <head>
            <script async src="cacheableNewsUpdaterEngine.js"></script>
        </head>
        <body>
            <xtal-method id="NewsUpdateManager">
                <ul role="target">
                    <li role="firstColumn">
                        <div role="topStory">
                        <img role="mainImage" src="someMainImage.png">
                        <span role="summary">Fierce Wildfires feast on Southern California</span>
                    </li>
                    ...
                </ul>
            </xtal-method>
        </body>
    </html>

The "cacheableNewsUpdaterEngine.js" is some cacheable script file (or collection of such files). There are two actors in this dance: The cacheableNewsUpdateEngine code (the "Manager") and the xtal-method code (the "Component")

  1. Manager: Loads the javascript for the xtal-method custom element.
  2. Manager: Defines functions that can render and derender the content of the news feed.
  3. Manager: Finds the xtal-method element by id, and sets the renderer and derenderer functions.
  4. Manager: Checks if the init-state property is set of the component. If not, attaches an event listener for init-state-changed.
  5. Component: After retrieving the original html, and the derenderer function, the derenderer function examines the original html content, and "derenders" it into a JavaScript array/objects, and that is passed via the init-state-changed event to the listener in step 4.
  6. Manager: On receiving the init state, object is placed in Manager's data store.
  7. Manager: Sets up a subscription so when the manager's data store is updated, it will update the component's input property.
  8. Manager: Using some polling or server-sent-events, or websockets, the javascript is informed from the server that there's been an update to the top story but no other changes. Only the top story update is sent down to the browser.
  9. Manager: Updates its store, which then gets passed to the input property of the component.
  10. Component: The renderer updates the UI (efficiently) based on the new input.

Scenario 2.

A cacheable template of static markup needs to insert some dynamic content inside a div, perhaps based on some user input (like filters). Then we need to update that content a little as the user edits things.

Since the template is cacheable, we can now feel free to inline the renderer and derenderer functions near the element right next to the div that contains the dynamic html.

But is there really any advantage of having a derenderer? I.e. in this scenario, is it faster to let the server build the html, and extract out the json from the html using a derenderer, or take the more traditional approach of the server generating json, and the client generating the html?

From a code maintenance point of view, it's almost certainly easier to do it all in the client. I.e. stick with JSON. This is probably the biggest explanation for why we had a stampede of logic flowing from the server to the client since 2005, and API's turned pure JSON-based. Until Twitter spotted the problem, AirBNB coined isomorphism, and later PWA's all made us start to rethink this.

So if we are targeting mobile devices, and performance is of utmost concern, which is better?

The answer would depend on so many scenarios, but I look at it this way:

  1. The server is likely to spend an equivalent amount of time generating either format. HTML might be a little more verbose than JSON, but then it can be compressed more efficiently, and streamed. So it is probably a wash.
  2. The CPU on the client will be about the same (just a guess, probably depends on a lot of things).
  3. Tie breaker: If the server sends html, we can display that immediately, then yield the thread, then (even in a separate worker thread if we really want to complicate things) apply the inverse function to form the initial state. We only need that inital state if other pieces of the page are binding to it. So why add extra work if it may not be needed? We know the HTML is needed, but the initial state might not be.

So based on this analysis, the advantage seems to go with generating html on the server, at least the first time.

Now, if we do need to bind on the client, and we cause incremental changes to the state, all within the browser, we have an efficient way of updating the UI, with the help of a smart renderer like lit-html or hyperHTML.

But what if we want to get a whole new batch of data from the server? Does it improve perforance if we get the data in JSON format from the server after the first batch, rather than HTML?

Typically, if we are talking about a list, the data won't change that much. The whole point of fancy renderers is they outperform setting innerHTML directly, as they can efficiently update only those parts that change. So here I suspect one would want to switch to the more traditional approach, and retrieve JSON.

To help manage this complex song and dance, xtal-method will expose to its peers whether the content displayed is the original content or not. This will allow other elements to know whether to retrieve HTML vs JSON should they agree that this analysis makes sense.

That markup could look as follows:

<xtal-method>
    <xtal-import-export>
    <script type="module ish">

        XtalIMEX.insert(_root_lit_html, _lit_html, _lit_repeat);
        const todoFormatter = items => html`
            <h1>My Todos</h1>
            <ul>
${repeat(items, item => item.id,  item => html`
                <li class="${item.done ? 'done' : ''}">${item.value}</li>
`)}
            </ul>
        `;
        export const renderer = (list, target) => render(todoFormatter(list), target);
        export const derenderer = el =>{
            const todos = [];
            el.querySelectorAll('li').forEach(element => {
                todos.push({
                    id: element.id,
                    value: element.innerText
                });
            });
            return todos;
        }
    </script>
    </xtal-import-export>
    <xtal-fetch fetch href="api/myTodos" role="target" as="text" insert-results>
    </xtal-fetch>
</xtal-method>

What this example illustrates, though, is that we need to know when to do the derender. One could use a mutation observer for that.

Install the Polymer-CLI

First, make sure you have the Polymer CLI installed. Then run polymer serve to serve your element locally.

Viewing Your Element

$ polymer serve

Running Tests

$ polymer test

Your application is already set up to be tested via web-component-tester. Run polymer test to run your application's test suite locally.
